Features
1. Advanced MPPT Technology
-
Advanced MPPT algorithm with up to 99.5% tracking efficiency
-
98% conversion efficiency for maximum solar energy utilization
- Stable operation under low-light or partial shading conditions
2. Flexible Battery Compatibility
-
Auto-detects 12V/24V systems for seamless integration
- Supports 8 + 1 battery types, including GEL, AGM, WET, CRYSTAL, CALCIUM, LiFePO₄, LTO, LCO, and Custom
-
Multi-stage charging algorithm with customizable parameters helps extend battery lifespan
3. Advanced Protection System
-
Multiple safety protections: Over-voltage, reverse polarity, short-circuit, and over-temperature
-
Weather-resistant build with IP43-rated PCBA and IP22 connectors
- Certified to ETL, FCC, CE, ROHS
4. Intelligent Monitoring System
-
LCD + LED display: Real-time solar input, battery status, and customizable parameters
-
Built-in Bluetooth for App monitoring (Rich Solar App)
-
Optional remote meter and temperature sensor for enhanced control
Specifications
-
Maximum Solar Input Current: 30A
-
Maximum Charging Current: 30A
-
Recommended Solar Power: 500W (12V) / 1000W (24V)
-
Nominal System Voltage: 12V/24V Auto-Detect
-
Solar Input Voltage Range: 8V-100V
-
MPPT Voltage Range: 15V-72V
-
Maximum Conversion Efficiency: 98%
-
Maximum MPPT Tracking Efficiency: 99.5%
-
Battery Compatibility: GEL, AGM, WET. CRYSTAL, CALCIUM, LiFePO., LTO, LCO, Custom
-
Connectivity: Built-in Bluetooth (Optional Remote Meter & Temperature Sensor)
-
Protection Rating: IP43 PCBA, IP22 Connection
-
Net Weight: 1.8 lb
-
Dimensions (LxWxH): 7.0 x 5.5 x 2.9 in
