Features
High-Efficiency MPPT Charging
-
99.5% MPPT Tracking Efficiency – Maximizes available solar energy harvest
- 98% Conversion Efficiency – Reduces power loss for higher system efficiency
Intelligent System Compatibility
-
Auto 12V / 24V Detection – Simplifies installation and setup
- Wide Battery Compatibility – Supports GEL, AGM, WET, CALCIUM, LiFePO₄, LTO, and LCO
Smart Monitoring & App Control
-
LCD Display – Real-time system status at a glance
- Bluetooth + App Support – Remote monitoring and parameter adjustment via smartphone
Reliable Built-In Protection & Certifications
-
Multi-Level Safety Protection – Protects against over-voltage, reverse polarity, short circuits, and overheating
-
Certified Safety & Compliance – ETL, CE, FCC, RoHS
Specifications
-
System Nominal Voltage: 12V/24V Auto
-
Maximum Solar Input Current: 40A
-
Maximum Charging Current: 40A
-
Recommended Solar Input Power: 600W(12V)/1200W(24V)
-
Solar Input Voltage Range: 8-100V
-
Standby Current: 10mA
-
Charging Technology: MPPT
-
MPPT Voltage Tracking Range: 15-72VDC
-
MPPT Efficiency: 99.5%
-
Conversion Efficiency: 98%
-
Battery Compatibility: GEL / AGM / WET / LFP / LTO / LCO / Crystal / Calcium / Customizable Battery
-
IP Grade: IP43
-
Operating Temperature: -13℉ ~ 122℉
-
Bluetooth: Yes
-
Options: External Battery Temperature Sensor; External Digital Remote Display
-
Dimensions: 8.3 × 6.1 × 2.2 in
-
Weight: 1.8 lb
-
Certifications: ETL, CE, FCC, RoHS
